QSC TSC-710T-G3 – 7″ Tabletop Touchscreen Controller (Gen 3 Series)

Table top mounting accessory for TSC-70-G3 and TSC-101-G3.

The QSC TSC-710T-G3 is a 7-inch tabletop touchscreen controller from the third generation of Q-SYS Touch Screen Controllers, purpose-built to provide user-friendly, customizable control in a sleek and compact tabletop format. This model combines a high-resolution capacitive touchscreen with a stable base for conference rooms, boardrooms, classrooms, and control hubs, where flexible and accessible AV control is required.

Designed to sit directly on a meeting table or flat surface, the TSC-710T-G3 connects over standard network infrastructure and supports Power-over-Ethernet (PoE) for easy installation. The integrated adjustable angle ensures comfortable use and visibility for end users.

Powered by Q-SYS Designer Software, this controller enables fully customizable User Control Interfaces (UCIs) to manage AV devices, lighting, environmental controls, scheduling, and more. The elegant form factor, edge-to-edge glass, and responsive UI make it a modern, intuitive choice for real-time control in smart AV environments.

Specifications

Specifications TSC-70-G3
Display
Description Projective capacitive (PCAP) multi-touch, PoE powered, 24-bit color display
Panel Dimensions (H×W×D) 4.5 x 7.3 x 1.54 in (115 x 185 x 39.1 mm)
Viewable Screen Size 7 inch / 177.8 mm (diagonal)
Resolution 1280 × 800
Wallmount Option Yes
Table Top Option Yes, with TSC-710T-G3 accessory (sold separately)
Panel Orientation Vertical / Horizontal (wall); Horizontal only (stand)
Brightness 400 Nits
Power
PoE (Power over Ethernet) PoE Class 3
Weight
Net Weight 1.2 lb (0.53 kg)
Environment
Operating Temperature 0°C – 50°C (32°F – 122°F)
BTUs 26 typical
Humidity 5% – 85% RH, non-condensing
Rear Panel LAN (1x RJ45) 1 Gbps

Features

  • Robust Responsiveness: Projective Capacitive (PCAP) Multi-Touch Surface with 24-bit Color Display
  • High Resolution Display: 1280 x 800 px with 400 Nits (brightness)
  • Power Over Ethernet: Allows for simplified single cable installation
  • Universal Mounting Options: Included accessories for mounting to US standard and European wall and junction boxes
  • Versatile: Ability to operate in portrait or landscape orientation
  • UCI Editor:
    • Easy Drag and Drop Interface: Drag and drop any control Q-SYS element from a Q-SYS design schematic into UCI Editor and easily deploy your design to the touch screen, without any programming experience. Q-SYS UCI Editor allows the import of room diagrams, corporate logos or other graphical elements in all major graphic file formats.
    • Complete Design Freedom: Build more dynamic UCI themes and apply global styles across multiple UCIs with CSS-based styling. Enables easier deployment of uniform UCIs across an organization.
    • Convenient License Activation: Deploying a UCI to an active Q-SYS system requires the UCI Deployment feature license.
  • AV Bridging: Connect a device to the TSC Series Gen 3 USB-C connector to integrate Q-SYS audio and camera feeds for remote meetings. Learn more about the AV Bridging feature license.

What’s in the Box ?

  • TSC‑710T‑G3 Tabletop Stand (Black)

  • Hardware kit for stand assembly (rubber feet, thumb screw, magnet dock)

  • Quick Start Guide & mounting instructions

  • Warranty and regulatory documentation

Additional Resources

User-Manual :

Download
