Sale!
, ,

Logic LG‑APM200 6.0 ft (200 cm) Motorized Projector Lift

With an extension of 150 cm, this high-quality projector mount provides a stable and smooth operationwith the maximum weight capacity of 15 kg.
Depth:- 550mm/Width:-576mm, Min Ceiling Depth:-800mm

The Logic LG‑APM200 is a premium-grade motorized projector lift featuring a robust aluminum build and a smooth tubular motor system. The lift silently extends up to an impressive 200 cm (approximately 6 ft), allowing seamless lowering and raising of your projector into and out of the ceiling cavity. Designed for professional AV installations in conference halls, classrooms, auditoriums, and high-end home theaters, the LG‑APM200 supports projectors up to 15 kg. It includes RF remote control, requires a minimum ceiling depth of 800 mm, and ensures elegant concealment when not in use. With quiet operation, durability, and a clean aesthetic, this lift elevates both functionality and design in modern AV setups.



Specifications

Feature Specification
Type Motorized Projector Lift
Model LG‑APM200
Brand Logic
Lift Travel 200 cm (6.0 ft)
Material Heavy-duty aluminum construction
Maximum Load Capacity 15 kg
Motor Type Tubular motor for smooth and quiet operation
Control RF remote control
Power Supply 220–230 V AC, 50 Hz
Minimum Ceiling Depth 800 mm
Overall Width (W) 576 mm
Overall Depth (D) 550 mm
Bottom Plate Size (W1 × D1) 490 × 490 mm
Closed Height (H1) 235 mm
Extended Height (H2) 1960 mm
Connecting Piece Length (L) 284 mm
Total Extended (H2 + L) 2244 mm
Recommended Projector Dimensions Under 400 × 190 × 400 mm
Product Weight 18 kg
Shipping Weight 20 kg
Shipping Dimensions 700 × 680 × 200 mm

Features

  • Extended reach up to 2 m—ideal for deep ceilings in auditoriums or boardrooms

  • Heavy-duty capacity: 15 kg for standard APM, 40 kg for EPM executive series

  • Smooth, quiet operation via dedicated tubular gear motor

  • Flexible controls: RF remote or serial control interfaces for AV integration

  • Precision build: Dual-arm design enhances stability and balance

  • Adaptable to room depth variations, supporting both APM and EPM installations

What’s in the Box ?

  • 1 × Motorized dual-arm lift mechanism (200 cm travel)

  • 1 × RF remote control

  • 1 × Power supply and regional AC cable

  • 1 × Ceiling installation kit (mounting brackets, fixings)

  • 1 × User manual & warranty documentation

Additional Resources

Data-Sheet :

Download
