Sale!
LG LSBE018 (1.88 mm pixel pitch) Indoor LED Signage Cabinet

LG LSBE018 (1.88 mm pixel pitch) Indoor LED Signage Cabinet

  • LG LSBE018 – 1.86 mm Indoor Active LED Cabinet

  • 600 nits brightness, excellent for indoor environments

  • Durable & serviceable: IP50 rated, flame-resistant, front access

  • Ideal for: retail, control rooms, corporate lobbies, broadcast sets

LSBE Indoor LED Series

Brightness

With a great brightness of 600 nits, it clearly delivers content and attracts public attention, making it ideal for achieving bright indoor visibility.


90° Corner Design Available

If you add 90° corner option, the LSBE series fits naturally into the space and delivers smooth content to customers.


GOB (Glue on Board) Protection Option

It features a special polymer coating for anti-scratch and anti-static protection, helping to reduce the risk of pixel damage from accidental touches or impacts.

* The GOB protection feature is optionally available for the following models: LSBE012-GDG, LSBE015-GDG, LSBE018-GDG, and LSBE025-GDG, as of April 2025.

Improved Flatness and Easy Maintenance

LSBE utilizes two modules to form a single cabinet, which helps minimize the gaps between modules compared to cabinets composed of multiple modules resulting in a smoother screen with fewer visible gaps. Moreover thanks to its structural advantage, LSBE allows for easy maintenance.


More Secure Maintenance with the Use of Safety Wire

When removing a module from the cabinets, the safety wire helps secure maintenance by preventing screen and module drops.

Durable Frame Design

LSBE incorporates an aluminum cabinet that enhances durability, and its high-strength frame, surpassing that of plastic, allows for stable operation.

Flame Spread Protection

LSBE is compliant with the standard for assessing flame spread, receiving a Class C rating according to the EN 13501-1:2018 test. With its fire resistance, LSBE contributes to the safety of your space.

* The test was conducted by SGS-CSTC Standards Technical Services (Shanghai) Co., LTD on Aug. 21 to 24, 2023, in accordance with the EN 13501-1:2018 standard. The LED module with product number (LSBE XX-XXX) was used as the test subject. The test results confirmed its compliance with the EN 13501-1:2018 Class C-s2, d0 rating.

Compatibility with LG Software Solutions

LSBE is compliant with the standard for assessing flame spread, receiving a Class C rating according to the EN 13501-1:2018 test. With its fire resistance, LSBE contributes to the safety of your space.


* The test was conducted by SGS-CSTC Standards Technical Services (Shanghai) Co., LTD on Aug. 21 to 24, 2023, in accordance with the EN 13501-1:2018 standard. The LED module with product number (LSBE XX-XXX) was used as the test subject. The test results confirmed its compliance with the EN 13501-1:2018 Class C-s2, d0 rating.

The LG LSBE018 is a high-quality 1.86 mm pixel pitch indoor active LED display, engineered for ultra-clear visuals and seamless video wall installations. With a brightness of 600 nits, it ensures vivid visibility even in well-lit indoor environments. Designed for premium signage, it provides fine pixel density ideal for short viewing distances such as in corporate lobbies, retail spaces, control rooms, and broadcast studios.

Its die-cast aluminum cabinet offers strong build quality with IP50 dust protection and Class C flame-resistance for enhanced safety. The LED modules are front-serviceable, and the cabinet supports 90° corner installations, allowing creative and flexible design layouts.

The display is compatible with LG’s signage ecosystem including CVBA controllers, SuperSign CMS, LED Assistant, and ConnectedCare. Built for 24/7 operation, the LSBE018 offers a long-lasting 100,000-hour lifespan to half brightness, making it a reliable solution for mission-critical applications.

Specification Table :

Feature Details
Pixel Pitch 1.86 mm
Cabinet Size 600 × 337.5 × 72 mm
Resolution (Per Cabinet) 320 × 180 pixels
Brightness 600 nits
Contrast Ratio 5,000:1
Viewing Angle (H/V) 160° / 150°
Color Uniformity ±0.003 Cx, Cy
Refresh Rate 3840 Hz
Frame Material Die-cast aluminum
Front Access Yes (full front serviceable)
Fire Rating EN 13501-1 Class C
Ingress Protection IP50 (Front & Rear)
Power (Avg / Max) 41 W / 103 W per cabinet
Lifetime 100,000 hours to half brightness
Mounting Options Wall-mount, 90° corner compatible
Supported Software CVBA Controller, SuperSign CMS, LED Assistant, ConnectedCare
Operation Hours 24/7 Commercial Use
