Barco ClickShare CX-50

High-end wireless conferencing for large meeting spaces and boardrooms

Interactive features: touchback, annotation and blackboarding
Increased collaboration with 2 sources on screen
Advanced network (dual Wi-Fi) and AV integration
HDMI™ input for high-quality content sharing
100% secure, encrypted and cloud managed

Specifications	Details
ClickShare Base Unit dimensions	Dimensions (HxWxD): 39mm x 200mm x 202mm
Power supply	Standard: 110/220 V AC plug
Power consumption	Operational: 50W (max)
	Standby: <8W (networked standby), < 0.5W (deep standby mode)
Weight	900 gr
General specifications
Operating system	Windows 10 or higher
	macOS 11 (BigSur) and higher
	Android v11 and higher (ClickShare App)
	iOS 14 and higher (ClickShare App)
System requirements	For a smooth experience with Microsoft Teams or Zoom
	Minimum: Intel i3 dual-core processor / 8GB RAM / OS: Windows 10 latest build or Mojave latest build
	Recommended: Intel i5 4-core processor / 8GB RAM / OS: Windows 10 latest build or Mac OS latest build
Video outputs	4K UHD (3840*2160) @ 30Hz. HDMI 1.4b
Video inputs	1920×1080 @30Hz. HDMI 1.4b
Audio output	USB, SPDIF, jack, HDMI
Connections	1x Ethernet LAN 1Gbit
	1x USB-C 2.0 (back); 2x USB-A 2.0 (back); 1x USB -A 2.0 (front)
	Audio analog line out on mini jack socket (3.5mm), digital S/PDIF
ClickShare Buttons	2
ClickShare App	Desktop & Mobile
Native protocols	Airplay, Google Cast, Miracast
Maximum number of simultaneous connections	32
Noise Level	Max. 25dBA @ 0-30°C
	Max. 30dBA @ 30-40°C
Authentication protocol	WPA2-PSK in stand-alone mode
	WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode
Wireless transmission protocol	IEEE 802.11 a/g/n/ac and IEEE 802.15.1
Reach	Max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit
Frequency band	2.4 GHZ and 5 GHz (DFS channels supported in select number of countries)
Temperature range	Operating: 0°C to +40°C (+32°F to +104°F)
	Max: 35°C (95°F) at 3000m
	Storage: -20°C to +60°C (-4°F to +140°F)
Humidity	Storage: 0 to 90% relative humidity, non-condensing
	Operation: 0 to 85% relative humidity, non-condensing
Anti-theft system	Kensington lock
Certifications	FCC/CE
Touch screen support & Interactivity	Yes
Wireless conferencing	via App or Button
Local view	High quality
Network connection	LAN & WiFi (dual)
Management and reporting	Yes
Warranty	1 year standard. 5 years coverage via SmartCare
