Ahuja SSA-5000DP – 500W 1-Channel Amplifier Mixer with Digital Player
Ahuja SSA-5000DP – 500W 1-Channel Amplifier Mixer with Digital Player - Image 2
Ahuja SSA-5000DP – 500W 1-Channel Amplifier Mixer with Digital Player - Image 3
Ahuja SSA-5000DP – 500W 1-Channel Amplifier Mixer with Digital Player - Image 4
,

Ahuja SSA-5000DP – 500W 1-Channel Amplifier Mixer with Digital Player

•500 Watt Amplifier Mixer Amplifier with Built-in Digital Player.
•7 Mic & 2 Aux Input for speeches, music, paging, etc.
•Built-in MP3 player with remote control for USB, SD/MMC card reader.
•4Ω/8Ω & 70/100V,Barrier Strip (with touch proof cover).
•Resettable circuit breaker for protection against overload and short circuit.

The Ahuja SSA-5000DP is a premium 500-watt, 1-channel amplifier mixer integrated with a built-in USB/SD digital MP3 player, ideal for high-powered public address applications. Engineered for delivering strong, distortion-free sound output across large areas, this model is perfect for large halls, outdoor events, religious congregations, and public functions.

Featuring multiple mic and aux inputs, tone controls, and digital audio playback, the SSA-5000DP provides an all-in-one audio solution. The digital player allows direct playback of music or pre-recorded announcements from USB drives or SD cards—eliminating the need for external players. Its built-in protection circuits ensure durability and reliable performance even under heavy load conditions.

With its robust design, flexible input options, and unmatched audio quality, the Ahuja SSA-5000DP stands out as a professional choice for high-demand sound systems.

Specifications

Power Output

750W Max., 500W RMS at 10% THD 450W RMS at 5% THD, 415W RMS at 2% THD

Output Regulation

≤ 2 dB, no load to full load at 1kHz

Input Channels

7 × Mic 0.8mV/4.7kΩ, 2 × Aux 100mV/470 kΩ,1 × CD 200mV/50 kΩ, 1 × Line 1V/50kΩ

Frequency Response

50-15,000Hz ±3dB

Signal to Noise Ratio

60dB

Tone Controls

Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHz

Output

Preamp 200mV/600Ω, Line 1V/1kΩ

Speaker Output

4Ω, 8Ω, 70V & 100V

Digital Player

MP3 Player with USB, SD and MMC Card Reader

Power Supply

AC: 220-240V 50/60Hz DC: 36V (3×12V Car Battery)

Power Consumption

AC: 1000VA DC: 8A

Dimensions

W510 × H172 × D385 mm

Weight

27.0kg

Additional Information :



Brand

AHUJA
FEATURES

USB option
MODEL

Single Zone
WATTAGE

201-500watts

What's in The Box?

  • Ahuja SSA‑5000DP Mixer Amplifier Unit

  • Remote Control (for digital player)

  • AC Power Cord

  • DC Backup Cable

  • Terminal Block Connectors

  • User Manual & Warranty Card

  • Spare Fuse

Additional Resources

Specification Sheet :

https://www.ahujaradios.com/Document/267-d2-SSA-5000DP_SP.pdf
